Comline® Nanofilter 3161 TUNZE

Comline® Nanofilter 3161

For fresh and saltwater from 30 to 100 liters depending on organic load (filter for nano aquariums) or 1,000 liters (surface filter).
Variable flow rate from 250 to 850 l/h.
Consumption: 2.5 to 4.5 W, 230V/50Hz (115V/60Hz)
Immersion depth: approx. 160 mm
Dimensions (L x W x H): 115 x 60 x 175 mm
Attachment by Magnet Holder up to 10 mm glass thickness.

Downloadable user manual at the bottom of the page

The TUNZE® Line of Components

Comline®, in tune with its time and environment, opens new doors with compact internal filters for aquariums, highly sophisticated and efficient, with pure lines. The Comline® is multifunctional: deep filtration with surface skimming, filtration with propeller pump, Flash Skimming, the forms blending to evoke a sense of Nature and simplicity in the aquarium. The goal remains the same, to offer the highest performance with the smallest possible footprint. And despite the internal vocation of these new filtration components, visual tranquility in the aquarium is guaranteed. It is no longer necessary to hide the filter in the aquarium because it is part of the aquarium. Regarding efficiency, organic load is eliminated directly and as close as possible to the waste producers. There are no intermediate steps or losses, the hydraulic paths are short, efficient, and direct, and the risk of flooding is nonexistent. This technique is extremely efficient, allowing for a reduction in its technical volume and electrical consumption.

Comline® Nanofilter 3161 is a very compact and silent internal filter with two compartments, designed in the famous "Comline®" style. It has surface and bottom skimming for nano aquariums in fresh and saltwater from 30 to 100 liters. But it is also a surface cleaner filter preventing the greasy film on the surface for larger aquariums, up to 1,000 liters. In this type of aquarium, especially if not equipped with surface skimming, Comline® Nanofilter 3161 will be able to work efficiently and will require little space in a corner of the tank. It features a low-consumption Comline® 900 pump, which can be adjusted to a low flow rate for small aquariums or a higher flow rate if used as a surface cleaner in large tanks. The filter is attached by a Magnet Holder Silence up to 10 mm glass thickness, with silicone silent blocks to prevent vibration transmission to the aquarium, particularly useful for small aquariums. For thicker glass, a Magnet Holder up to 15 mm can be used (accessories).

The first chamber of the filter, all in depth, receives approx. 15% of the treated water flow and is specially designed for placing a nano heater (in small tanks) or pH or temperature probes (for larger tanks). The main filtration chamber allows for the placement of perlon wool or any other filtration substrate, and it is equipped with additional filtration foam, easy to remove.
Comline® Nanofilter 3161 is delivered ready to use, with filter media.

Adjustable surface skimming, allows...
placement of the filter in all corners of the aquarium. It is possible to stack two skimmings.

Attachment by Magnet Holder Silence

patented up to 10 mm glass thickness.

First chamber for the placement of a nano heater, probes, or biological media.

Bottom skimming (approx. 15% of the pump flow) for capturing waste in open water.
Low-consumption Comline® 900 pump, highly energy-efficient and adjustable from 250 to 850 l/h.
Consumption 2.5 to 4.5 W.

Main chamber (approx. 85% of the pump flow) with a volume of 250 cm³, can be filled with all kinds of fine or coarse perlon, activated carbon, or other filtration media.

Lid above the filtration chamber, for easy filter media change.

Rear lid, can remain closed for probes or heater
